Xtreme Motorsport 200mm twin plate
The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality.The 200mm Race Clutch Kits consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC). Product Features:
- Torque capacity 1200Nm
- Kit contains everything you need for a successful installation + accessories
- Rigid driven discs (individual hubs)
- Push type billet alloy cover
- 4140 Chromoly pressure & intermediate plates
- Hardened steel wear posts
- Low inertia
- Serviceable components
- SFI certified design
| Clamping Force | 1000kg |
| Torque Rating | 1200Nm |
| Bearing Contact Diameter | 44-52mm |
| Bearing Load (@ 48mm) | 218kg |
| Release Travel Required | 6mm |
| Assembly Mass (without flywheel) | 7kg |
| Disc Set Static Mass | 1.75kg |
| Friction Thickness New | 7mm (0.275") |
| Friction Thickness Worn | 6.48mm (0.255") |
Passar till:
- Mazda RX-8 1.3 (FE103. SE3P) 2003.10-2012.06 13B-MSP 1308 Petrol 141 kW 192 BHP (2003.10 - 2012.06)Mazda RX-8 1.3 2003.11-2012.06 13B-MSP 1308 Petrol 158 kW 215 BHP (2003.11 - 2012.06)
Mazda RX-8 1.3 (FE103. SE3P) 2003.10-2012.06 13B-MSP 1308 Petrol 170 kW 231 BHP (2003.10 - 2012.06)
Mazda RX-8 1.3 (SE3P) 2003.11-2012.06 13B-MSP 1308 Petrol 177 kW 241 BHP (2003.11 - 2012.06)
