PWM Fan Controller 12V/24V DC - 10A
Compact and adjustable PWM (Pulse Width Modulation) controller for variable speed control of DC fans and other electrical DC loads. The controller allows you to easily adjust fan speed to suit your requirements using a manually operated rotary potentiometer.
Ideal for automotive applications, motorsport, cooling systems and other installations where precise control of airflow and fan speed is required. It can also be used to control DC motors, incandescent lamps and LED lighting with current-limiting resistors.
Specifications:
Operating voltage: 9–28V DC (suitable for 12V and 24V systems)
Maximum current: 10A (with adequate cooling)
Maximum current without additional cooling: 5A
Control range: Approximately 5–95%
PWM input signal: 10 Hz–10 kHz at 5V
Potentiometer: 4.7 kΩ linear
Connections: 6 x 6.3 mm spade terminals
