Xtreme Motorsport 184mm twin plate
Designed for high powered circuit, time attack or gymkhana applications, the Xtreme 184mm Race Clutch offers quick shift times and a lightweight construction. The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts. Product Features:
- Push type billet alloy cover
- 4140 Chromoly pressure plate
- Hardened steel wear posts
- High and low ratio pressure plate options
- Low inertia
- Serviceable components
- SFI certified design
Replacement Parts | Light Diaphragm Alloy Hat Assembly (2.6mm) | 185-10B-PP-L | Heavy Diaphragm Alloy Hat Assembly (2.8mm) | 185-10B-PP | Pressure Plate Casting | 185-10B-PPC | Intermediate Plate | 185-10B-IP | Pressure Plate Bolt | BOLT-8X1.125X50 | Pressure Plate Washer | WASHER-8MM-C |
| Ø184mm Light Diaphragm (2.6mm) | Ø184mm Heavy Diaphragm (2.8mm) | |
| Clamping Force | 950kg | 1080kg |
| Torque Rating | 1060Nm | 1210Nm |
| Bearing Contact Diameter | 44-52mm | |
| Bearing Load (@ 48mm) | 210kg | 260kg |
| Release Travel Required | 5mm | |
| Assembly Mass (without flywheel) | 4.45kg | |
| Disc Set Static Mass | 1.1kg | |
| Friction Thickness New | 6.35mm (0.250") | |
| Friction Thickness Worn | 5.97mm (0.235") | |
Passar till:
- Mitsubishi Lancer EVO VIII - 260 (CT9A) 2004.03-2005.07 4G63 Turbo 1997 Petrol 195 kW 265 BHP (2004.03 - 2005.07)Mitsubishi Lancer EVO VII (CT9A) 2001.01-2003.01 4G63 Turbo 1997 Petrol 200 kW 272 BHP (2001.01 - 2003.01)
Mitsubishi Lancer EVO IV (CN9A) 1996.08-1997.12 4G63 Turbo 1997 Petrol 206 kW 280 BHP (1996.08 - 1997.12)
Mitsubishi Lancer EVO V (CP9A. CT9A) 1998.01-1998.12 4G63 Turbo 1997 Petrol 206 kW 280 BHP (1998.01 - 1998.12)
Mitsubishi Lancer EVO VII (CT9A) 2001.01-2003.01 4G63 Turbo 1997 Petrol 206 kW 280 BHP (2001.01 - 2003.01)
Mitsubishi Lancer EVO VIII (CT9A) 2003.04-2005.03 4G63 Turbo 1997 Petrol 206 kW 280 BHP (2003.04 - 2005.03)
Mitsubishi Lancer EVO IX (CT9A) 2005.01-2007.09 4G63 Turbo 1997 Petrol 206 kW 280 BHP (2005.01 - 2007.09)
Mitsubishi Lancer EVO VI (CP9A) 1999.01-2001.02 4G63 Turbo 1997 Petrol 207 kW 281 BHP (1999.01 - 2001.02)
Mitsubishi Lancer EVO IX (CT9A) 2005.08-2006.09 4G63 Turbo 1997 Petrol 213 kW 290 BHP (2005.08 - 2006.09)
Mitsubishi Lancer EVO VIII - FQ-300 (CT9A) 2003.04-2004.04 4G63 Turbo 1997 Petrol 225 kW 305 BHP (2003.04 - 2004.04)
Mitsubishi Lancer EVO VIII - FQ-300 (CT9A) 2003.04-2004.04 4G63 Turbo 1997 Petrol 227 kW 309 BHP (2003.04 - 2004.04)
Mitsubishi Lancer EVO IX - FQ-300 (CT9A) 2005.06-2006.12 4G63 Turbo 1997 Petrol 227 kW 309 BHP (2005.06 - 2006.12)
Mitsubishi Lancer EVO VIII - FQ-320 (CT9A) 2004.04-2006.08 4G63 Turbo 1997 Petrol 243 kW 331 BHP (2004.04 - 2006.08)
Mitsubishi Lancer EVO VIII - FQ-330 (CT9A) 2003.10-2006.08 4G63 Turbo 1997 Petrol 246 kW 335 BHP (2003.10 - 2006.08)
Mitsubishi Lancer EVO VIII - FQ-340 (CT9A) 2004.04-2005.03 4G63 Turbo 1997 Petrol 255 kW 347 BHP (2004.04 - 2005.03)
Mitsubishi Lancer EVO IX - FQ-340 (CT9A) 2005.06-2007.12 4G63 Turbo 1997 Petrol 257 kW 350 BHP (2005.06 - 2007.12)
Mitsubishi Lancer EVO IX - FQ-360 (CT9A) 2006.07-2007.12 4G63 Turbo 1997 Petrol 273 kW 371 BHP (2006.07 - 2007.12)
Mitsubishi Lancer EVO VIII - FQ-400 (CT9A) 2004.10-2006.08 4G63 Turbo 1997 Petrol 302 kW 411 BHP (2004.10 - 2006.08)
Mitsubishi Lancer EVO V - RS450 Ralliart (CP9A) 1998.01-1998.06 4G63 Turbo 1997 Petrol 336 kW 456 BHP (1998.01 - 1998.06)
