Turbosmart Ford 1.0L EcoBoost Kompact Dual Port Shortie - Blow-Off Valve

Name: BOV Kompact Dual Port Shortie Ford 1L Ecoboost
Brand: Turbosmart
SKU: TS-0203-1066
Price: 365 EUR
Availability: InStock

The Turbosmart Kompact Dual Port Shortie is a high-performance blow-off valve designed for the Ford 1.0L EcoBoost. It replaces the factory-fitted bypass valve and offers improved durability, quick response and reliable boost management for both standard engines and modified performance builds.

The valve features a precision-machined billet aluminium body and a piston with O-ring seals. Unlike the factory valve's plastic diaphragm construction, Turbosmart's design is engineered to withstand higher boost pressures and reduce the risk of leakage over time.

Dual Port – Two Functions in One Valve

The Dual Port design releases approximately 50% of excess air into the atmosphere and recirculates the remaining 50% back into the intake system. This produces the characteristic blow-off sound under higher boost conditions, while recirculation helps maintain quieter operation at lower loads.

The compact Shortie design is intended for direct installation in the designated factory location. Installation is designed as a bolt-on upgrade and normally requires no extensive modifications.

Features and Benefits

Ford 1.0L EcoBoost: Vehicle-specific replacement for the factory electronic bypass valve.
Dual Port technology: Splits airflow between atmospheric discharge and recirculation.
Billet aluminium: Robust and durable construction.
Sealed piston design: O-rings help provide effective sealing and reduce boost leakage.
Fast response: Designed for efficient pressure release during throttle lift-off.
Compact Shortie design: Designed to fit in the original installation location.
Suitable for standard and modified engines: An upgrade for improved durability and boost system performance.

Technical Specifications

Manufacturer: Turbosmart
Model: Kompact Dual Port Shortie
Product type: Blow-off valve / bypass valve
Fitment: Ford 1.0L EcoBoost, subject to the manufacturer's vehicle application
Construction: Precision-machined billet aluminium
Valve type: Dual Port, atmospheric discharge and recirculation
Installation: Direct replacement for the factory valve

Product video

Technical specification

Article nr:

TS-0203-1066

Manufacture Partnumber:

TS-0203-1066

Turbosmart was founded in Sydney, Australia, in 1997. At the time they only had 2 products but quickly became known in the car industry for their incredible quality and durability.

Today Turbosmart's products are sold in more than 50 countries around the world and is found in several record-breaking cars. The successes and tests of these cars on and off the track, Turbosmart has taken part in their development of products. This means that Turbosmart's products never stop developing, they make constant updates to get the absolute best results. The assortment offers wastegates, blow-off valves, boost controllers and gauges etc.
