The MagnaFlow Overland Series Cat-Back Performance Exhaust System #19636 is engineered for off-road functionality and built to explore further, making it the perfect upgrade for your 2024–2025 Ford Ranger equipped with the 2.3L I4 engine. Designed with durability, clearance, and sound control in mind, this system delivers proven performance and MagnaFlow’s signature exhaust tone.
The system features a high-clearance exhaust design that helps keep vital components protected from obstacles and challenging terrain. Its 3-inch mandrel-bent main piping flows through an 18-inch straight-through oval muffler and a No Drone Technology (NDT) tuned chamber, before exiting through a high-clearance single rear passenger-side outlet.
MagnaFlow’s No Drone Technology (NDT) utilizes passive quarter-wave noise cancellation to reduce unwanted droning that can occur during highway cruising. Exhaust system #19636 also offers exceptional sound tunability via an integrated muffler accessory port, allowing drivers to fine-tune their exhaust note to personal preference. The included pipe cap, J-pipe, and NDT modules can be installed in various combinations to address a wide range of droning frequencies.
For a smoother and quieter ride on the trail, simply install the NDT module. If a more aggressive and free-flowing MagnaFlow sound is desired, the pipe cap can be installed to close the accessory port.
This cat-back exhaust system features a direct-fit, easy-to-install design that replaces the factory exhaust components from the catalytic converter back. Constructed from durable, corrosion-resistant stainless steel and manufactured using advanced CNC precision robotic techniques, exhaust system #19636 is backed by MagnaFlow’s limited lifetime warranty.
Specifications
Series: Overland Series
Product Type: Cat-Back Performance Exhaust System
Material: Stainless Steel
Pipe Diameter: 3"
Pipe Construction: Mandrel-bent tubing
Muffler Type: 18” oval straight-through muffler
Resonator: NDT tuned chamber
No Drone Technology: Yes
Sound Tunability: Interchangeable modules (pipe cap, J-pipe, NDT module)
Exhaust Exit: High-clearance single rear passenger-side exit
Design Focus: Increased ground clearance for off-road use
Installation: Direct-fit, replaces exhaust from the catalytic converter back
Manufacturing Method: CNC precision robotic manufacturing
Warranty: Limited lifetime warranty
