KSU20631-3E - Clutch Kit - Xtreme Performance 200mm Rigid Ceramic Triplate Plate Incl Flywheel & CSC

Article nr:
xtcKSU20631-3E
|
(0 reviews)
Xtreme Clutch delivers ultra‑strong clutch kits for motorsport and tuned cars - twin‑plate options handle up to ~1000 Nm.
2223 EUR
Delivery:  Out of stock
Warehouse stock:  0
Stock: 0

Sales Representative Image

Talk to an expert

Need help? Check fitment, get personalized recommendations and tips.

Contact us

  • Product description
  • -2E

    The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality. The 200mm Race Clutch Kit’s consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC).

    Clamping Force 1000kg
    Torque Rating 1200Nm
    Bearing Contact Diameter 44-52mm
    Bearing Load (@ 48mm) 218kg
    Release Travel Required 6mm
    Assembly Mass (without flywheel) 7kg
    Disc Set Static Mass 1.75kg
    Friction Thickness New 7mm (0.275")
    Friction Thickness Worn 6.48mm (0.255")

    Product Features:

    • Rigid driven discs (individual hubs)
    • Push type billet alloy cover
    • 4140 Chromoly pressure & intermediate plates
    • Hardened steel wear posts
    • Low inertia
    • Serviceable components
    • SFI certified design

    Passar till:

    Product video

    Technical specification

    Article nr:
    xtcKSU20631-3E
    Manufacture Partnumber: KSU20631-3E
  • Suitable for
  • Brand
  • Xtreme Clutch Xtreme Clutch has been at the forefront of performance clutch technology for decades. Our in house testing machinery and close bonds with motorsport has allowed us to do extensive testing on various combinations of material and disc designs to suit high performance and racing applications. The Xtreme Clutch name has become synonymous with high performance.
