Xtreme Motorsport 184mm twin plate
Designed for high powered circuit, time attack or gymkhana applications, the Xtreme 184mm Race Clutch offers quick shift times and a lightweight construction. The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts. Product Features:
- Push type billet alloy cover
- 4140 Chromoly pressure plate
- Hardened steel wear posts
- High and low ratio pressure plate options
- Low inertia
- Serviceable components
- SFI certified design
Replacement Parts | Light Diaphragm Alloy Hat Assembly (2.6mm) | 185-10B-PP-L | Heavy Diaphragm Alloy Hat Assembly (2.8mm) | 185-10B-PP | Pressure Plate Casting | 185-10B-PPC | Intermediate Plate | 185-10B-IP | Pressure Plate Bolt | BOLT-8X1.125X50 | Pressure Plate Washer | WASHER-8MM-C |
| Ø184mm Light Diaphragm (2.6mm) | Ø184mm Heavy Diaphragm (2.8mm) | |
| Clamping Force | 950kg | 1080kg |
| Torque Rating | 1060Nm | 1210Nm |
| Bearing Contact Diameter | 44-52mm | |
| Bearing Load (@ 48mm) | 210kg | 260kg |
| Release Travel Required | 5mm | |
| Assembly Mass (without flywheel) | 4.45kg | |
| Disc Set Static Mass | 1.1kg | |
| Friction Thickness New | 6.35mm (0.250") | |
| Friction Thickness Worn | 5.97mm (0.235") | |
Passar till:
- Nissan Almera Tino 2.0 2000.08-2003.01 SR20DE 1998 Petrol 100 kW 136 BHP (2000.08 - 2003.01)Nissan Sunny N14 | 2.0 1990.08-1996.12 SR20DE 1998 Petrol 104 kW 141 BHP (1990.08 - 1996.12)
Nissan Sunny N14 | 2.0 GTI 16V 1990.10-1995.05 SR20DE 1998 Petrol 105 kW 143 BHP (1990.10 - 1995.05)
Nissan Sunny N14 | 2.0 i 16V 1990.10-1995.05 SR20DE 1998 Petrol 105 kW 143 BHP (1990.10 - 1995.05)
Nissan 100NX 2.0 GTI (B13) 1991.03-1994.10 SR20DE 1998 Petrol 105 kW 143 BHP (1991.03 - 1994.10)
Nissan Sunny N14 | 2.0 1991.10-1993.05 SR20DE 1998 Petrol 105 kW 143 BHP (1991.10 - 1993.05)
Nissan Primera P11 | 2.0 16V 1996.06-2001.12 SR20DE 1998 Petrol 105 kW 143 BHP (1996.06 - 2001.12)
Nissan Almera 2.0 GTi (N15) 1996.07-2000.03 SR20DE 1998 Petrol 105 kW 143 BHP (1996.07 - 2000.03)
Nissan 100NX 2.0 (B13) 1990.10-1994.10 SR20DE 1998 Petrol 110 kW 150 BHP (1990.10 - 1994.10)
Nissan Primera P11 | 2.0 16V 1996.09-2002.07 SR20DE 1998 Petrol 110 kW 150 BHP (1996.09 - 2002.07)
Nissan Primera P11 | 2.0 16V 1996.09-2002.07 SR20De 1998 Petrol 85 kW 115 BHP (1996.09 - 2002.07)
Nissan Primera P11 | 2.0 16V 1996.09-2002.07 SR20DE 1998 Petrol 96 kW 131 BHP (1996.09 - 2002.07)
